Tootekood: 6216-2RS1/C3 Kategooriad: , Silt:

Kirjeldus

6216-2RS1/C3
Deep groove ball bearing with seals or shields
Single row deep groove ball bearings with seals or shields are particularly versatile, have low friction and are optimized for low noise and low vibration, which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than many other bearing types. The integral sealing can significantly prolong bearing service life because it keeps lubricant in the bearings and contaminants out.
Integral sealing prolongs bearing service life
Simple, versatile and robust design
Low friction and high-speed capability
Accommodate radial and axial loads in both directions
Require little maintenance

DIMENSIONS
Bore diameter 80 mm
Outside diameter 140 mm
Width 26 mm

PERFORMANCE
Basic dynamic load rating 72.8 kN
Basic static load rating 55 kN
Reference speed 9500 r/min
Limiting speed 3000 r/min
SKF performance class SKF Explorer

PROPERTIES
Filling slots Without
Number of rows 1
Locating feature, bearing outer ring None
Bore type Cylindrical
Cage Sheet metal
Matched arrangement No
Radial internal clearance C3
Material, bearing Bearing steel
Coating Without
Sealing Seal on both sides
Sealing type Contact
Lubricant Grease
Relubrication feature Without
